Method for setting vee block centrally to machine spindle

Hi All

This is the method I use for setting a vee block centrally to machine spindle.
This is a quick method for setting up a vee block centrally to the machine spindle, be it a on a drill or mill.

The first picture shows a piece of material which has been machined square in the lathe and is the setting piece.

Attachment 21614

The second photo shows the setting bar being lowered in to the vee of the block using the machines quill. This centralises the vee block to the spindle.

Attachment 21615

The third photo shows a parallel being clamped against the base of the vee block. This needs to be tighten and square to the block.

Attachment 21616

The forth photo shows the vee block being moved along the parallel. This enables the work piece to be position without machining into the vee block but still maintaining the central position. (In this case I didn’t need to use the parallel as it is a piece of tube and I am only drill one side of the wall.

Attachment 21617

The fifth photo shows the clamping of the vee block to the table, the left clamp is operated first with the vee block still against the clamped parallel to ensure the position is maintained.

Attachment 21618

The sixth photo shows the parallel removed and the second clamp in position to ensure good clamping of the vee block.

Attachment 21619

The seventh photo shows the centre drill ready to drill the component on its centre line.

Attachment 21620

The setting bar is also used to clamp the vee block and horse shoe clamp together for storing.

Attachment 21632

This isn’t a home-made tool but I hope you have found this useful for any future projects you where you might need to drill on the centre line of a shaft.

The Home Engineer

<!-- BEGIN /var/www/html/homemadetools/protected/modules/zeus/views/tool/postUpdate.php -->
Thanks thehomeengineer! We've added your Vee Block Centering Method to our Measuring and Marking category,
as well as to your builder page: thehomeengineer's Homemade Tools. Your receipt:

<div id="blocks"> <div class="block b1 pngfix"> <div class="bimg"> <div> <a href="http://www.homemadetools.net/homemade-vee-block-centering-method"> <img src="/uploads/209315/homemade-vee-block-centering-method.jpeg"/> </a> </div> </div> <div class="head pngfix"></div> <div class="left pngfix"></div> <div class="right pngfix"></div> <div class="blockover b1 pngfix"> <div class="title"> <a href="http://www.homemadetools.net/homemade-vee-block-centering-method">Vee Block Centering Method</a> <span> by <a href="http://www.homemadetools.net/builder/thehomeengineer">thehomeengineer</a></span> </div> <div class="tags">tags: <a href='http://www.homemadetools.net/tag/centering'>centering</a> </div> </div> </div> </div>
<!-- END /var/www/html/homemadetools/protected/modules/zeus/views/tool/postUpdate.php -->

Love those holddown clamps!!

Can't wait to make some.

Thanks for posting I need this.

Ralph

Hello and AWESOME work! Any chance you can add the specs of those clamps in the pictures? They look very useful and just what I’m looking for.
Thanks again,
MoBo

Hi
thank you for your interest below is a link to the claw clamp drawings in the plans for sale forum.
https://www.homemadetools.net/forum/claw-clamps-68771
many thanks again
The Home Engineer

Thanks bought it!!

Ralph

Hi Ralph
Thank you for purchasing the drawings I would appreciate any feedback good or bad on the content of the drawing pack. I would also like to see some photos once you have completed them.
All the best
The Home Engineer

Don't hold your breath waiting to see what I might do with the Claw Clamps. They are on a very long ToDo list.

I really like having drawings as you just never know what opportunities might arise, at least having the drawings ...

Ralph

I know exactly what you mean someone bought me a sign that said: “I have so many projects and I am so far behind, I haven’t got time to die.”

But if you do get a chance to make I am sure you won’t be disappointed I use mine all the time. I have made at least 8 large ones and two half size. I have adapted some Bosch extrusion as packers so the height can be increased to hold larger/ higher components. I will post to show you in a new post.

Link to Bosch extrusion packers for claw clamps
http://www.homemadetools.net/forum/c...p-system-65679

I'm not a machinist so when I see things like this I do find them very helpful. Thank you. Mr Mikey.

Strange the V-block is at a angle to the table. I suppose if you are only drilling one hole it doesn't matter.

Ralph
